Description
Barrel Length: 18"
Gas System: Rifle-length
Barrel Profile: A2 Style
Barrel Steel: 416R
Barrel Finish: Stainless Steel
Chrome Lining: None
Muzzle Thread: 5/8-24
Chamber: 6.5 Grendel; Type 2
Twist Rate: 1:8
Barrel Extension: M4
Diameter at Gas Block: .750
Gas Block Type: Low profile adjustable gas block
Muzzle Device: A2 Flash Hider
Receiver Material: Forged 7075 T6
Receiver Type: M4
Handguard Type: PSA 15" Lightweight M-Lok Free Float Rail
Bolt Carrier Group Included: Yes
Bolt Steel: 9310, Nitride Coated
Bolt Carrier Profile: Full-auto
Charging Handle Included: Yes
Optic: Vortex Senora 4-12x44 Riflescope w/Dead-Hold Reticle
Mount: Vortex Cantilever Ring Mount for 1" Tube with 2" Offset
Overall Length: 26.5"
FEATURES
Barrel: 416R Stainless steel. Chambered in 6.5 Grendel, with a 1:8 twist, M4 barrel extension, and a rifle-length gas system. Barrel is finished off with a PSA 15" Lightweight M-Lok free float rail, .750 adjustable gas block, and A2 flash hider.
Upper: Forged 7075-T6 A3 AR upper is machined to MIL-SPECS and hard coat anodized. These uppers are made for us right here in the USA by a mil-spec manufacturer.
Bolt: Full-auto profile bolt carrier group. 9310 steel bolt, Shot Peened, Gas Key Hardened to USGI Specifications, Fastened with Grade 8 screws, and Staked Per Mil-Spec. 8620 steel M-16 profile carrier is nitride treated.
Vortex Sonora 4-12x44 Riflescope w/ Dead-Hold BDC Reticle
The Vortex Sonora redefines what a rifle scope can do. The Sonora combines fully multi-coated lenses for a clear sight picture with generous eye relief. The Sonora also features a hard-anodized, single-piece, aircraft-grade aluminum tube that is nitrogen purged and O-ring sealed that delivers a waterproof, fog-proof, weatherproof performance no matter the weather.
Features:
Anti-reflective lens coatings increase light transmission for greater clarity
Gas purged and o-ring sealed delivering waterproof and fog-proof performance
Waterproof performance designed to withstand harsh weather conditions
The shockproof, rugged construction withstands the highest levels of recoil and impact
Specifications:
Reticle: Dead-Hold BDC
Tube Size: 1"
Length: 13.5"
Weight: 15.8 oz.
Eye Relief: 4"
Field of View: 24.7'-8.4' @ 100 Yard
Adjustment: 1/4 MOA
Travel Per Rotation: 15 MOA
Total Windage Travel: 60 MOA
Total Elevation Travel: 60 MOA
Vortex Cantilever Ring Mount For 1" Tube with 2" Offset
Use this cantilever mount for mounting 1-inch telescopic sights onto flattop style AR-15 rifles. The 2-inch offset of this cantilever mount positions the scope in a forward location, allowing the correct eye relief and head placement on an AR-15. Aluminum construction.
Features:
The cantilever ring mount positions the center of the riflescope tube at a height of 1.59 inches (40.39 mm) from the base.
Specifications:
Model: CM-102
Mount Style: Cantilever
Offset: 2"
Rings: 1"
Weight: 6.7 oz.
Ring Screw Torque: 16 inch/lbs
Base Screw Torque: 20 inch/lbs
